DYNAMIC ANALYSIS OF FIBER-REINFORCED POLYMER COMPOSITE ELECTRIC POLES |
|---|---|
| รหัสดีโอไอ | |
| Title | DYNAMIC ANALYSIS OF FIBER-REINFORCED POLYMER COMPOSITE ELECTRIC POLES |
| Creator | Sara Mohamadi, Girum Urgessa |
| Contributor | - |
| Publisher | ISEC PRESS |
| Publication Year | 2560 |
| Keyword | FRP, Fiber orientation, Dynamic analysis, Taper ratio, Lamina thickness |
| Abstract | This paper presents finite element modeling of tapered FRP poles in ABAQUS for dynamic analysis. Modal analysis and transient dynamic analysis are presented in order to evaluate the effect of fiber orientation, taper ratio, number of layers and lamina thickness on the dynamic properties of tapered poles. Trends observed from parametric studies on the analyses of the FRP poles are enumerated. In addition, the effect of rectangular dynamic excitations on the overall response of the poles is presented representing impulsive loadings that may occur due to wind gusts or loss of cable tension supporting the FRP poles. Result shows that the fundamental frequency of the poles decreased as the fiber-orientation increased up to 60 degrees. In addition, the fundamental frequency of the poles increased as the number of layers increased. No significant difference was observed in natural frequency when varying the lamina thickness without changing the overall laminate thickness. The fundamental frequency of the poles decreased by 10% as the taper ratio increased from 0.4 to 1. Transient dynamic analysis showed that poles with higher fiber orientation angle had the larger maximum tip deflection. However, only small differences were observed when the deflections are normalized as the ratio of the maximum dynamic to static deformation. |
| ISBN | 978-0-9960437-4-8 |
